产品概述

　　设备工艺流程

　　原料人工对位放料→排气挤压→长度方向对折2次→宽度方向折叠2次→挤压式码料→制品在集料槽中排列挤压→人工取料。

　　*产品折叠位置可在触摸屏上微调。

　　设备的主要配置：

　　1、触摸屏操控，傻瓜式操作，界面简洁，折叠位置可微调；

　　2、整机工业铝型材架构，配备地脚及脚轮，移动便捷，生产稳重；

　　3.采用星辰气动、台湾永宏PLC、欧姆龙编码器及威纶触摸屏；

　　4.材料上机后配合滚轮排气挤压，压缩产品厚度；

　　5、折板接触面采用304不锈钢材料制作；

　　6、弹压式集料槽，成品挤压定型；

　　7、全程可视化操作，可另配飞标计数装置；

　　8、配工具一套.

　　Manual counter feeding of raw materials----Exhaust extrusion--Fold the length twice---Fold the width twice--Extruded feeding----The products are arranged and extruded in the aggregate tank--Artificial take the products

The folding position of the product can be fine-tuned on the touch screen

Touch screen control, fool-operation, simple interface, folding position can be fine-tuned;

　　Complete machine industrial aluminum structure, equipped with foot and casters, easy to move, stable production

Adopt star pneumatic, Taiwan Yonghong PLC, Omron encoder and Wylan touch screen

　　Material on the machine with the roller exhaust extrusion, compression product thickness

　　The contact surface of the folding plate is made of 304 stainless steel

Spring - pressure aggregate groove, finished product extrusion finalize

The whole visual operation can be equipped with another flying standard counting device

　　A set of tools attached
